6
EURO BRAKE ASSEMBLY
No. Part No. Description Qty.
1 25-0316-2 AXLE CABLE SHELL 2
2 25-0316-11 BACK PLATE CAP 2
3 25-0316-12 COVER 2
4 25-0316-13 LOCKING NUT 2
5 25-0316-14 COVER PLATE 2
6 25-0316-15 PLASTIC LUG 4
7 25-0316-10 ADJUSTER ASSEMBLY COMPLETE 2
8 25-0316-16 REVERSE LEVER LH SIDE 1
25-0316-17 REVERSE LEVER RH SIDE 1
9 25-0316-18 SPLIT PIN 2
10 25-0316-19 SHOE RETAINING SPRING 2
11 25-0316-20 BEARING BOLT 2
12 25-0316-6 COMPLETE DRUM 2
13 25-0316-4 AXLE FLANGE NUT - DO NOT RE-USE 2
14 25-0316-21 DUST CAP 2
15 25-0316-22 WHEEL BOLT 8
16 25-0316-26 EXPANDING CLUTCH 2
17 25-0316-7 AXLE PULL OFF SPRING 2
18 25-0316-5 BRAKE SHOES 2
19 25-0316-25 STUB AXLE - NOT SUPPLIED LOOSE 2
20 25-0316-24 CABLE EYE 2
21 25-0316-8 AXLE BOWDEN CABLE 2
22 25-0316-23 REVERSE LEVER SPRING 2
