General Specifications, Standard Machine X27RT
page 3 - 2 Rev A SR3370 & SR2770 – 13184A
3. Specifications
SPECIFICATIONS X27RT
Nominal working height
10.28m 33' 9”
Roll out deck size
1200mm 48”
Drive speed (below 2.4m)
0 to 4.5kph 0 to 2.8mph
Drive speed (above 2.4m)
0 to 0.9kph 0 to 0.6mph
Safe working load - Main deck
(Roll out deck not extended)
580kg 1280lbs
Safe working load - Main deck
Roll out deck extended - Roll out
deck
460kg
120kg
1015lbs
265lbs
Platform size
2.73 x 1.65m 8’ 11” x 5’ 5”
Stowed height
2.5m 8' 2"
Stowed height (hand rails folded down)
1.7m 5' 8"
Overall length
3.36m 11’ 0”
Overall width
1.7m 5' 8"
Gradeability
35%
Lift time
26 seconds
Turning radius (inner)
2.83m 9’ 3”
Turning radius (outer)
4.6m 15’ 1”
Maximum wind speed (12.5m/s)
45km/h 28mph
Insulation rating
Nil
Tyres - Poly filled loader lug
27" x 10.5" x 15"
Overall weight
2800kg 6272lbs
Ground clearance
350mm 13.8”
Maximum sound level at platform
86db
