Upright X33RT - Placards and Decals

page 7 - 10 Rev A SR3370 & SR2770 – 13184A
7. Daily Inspection and Maintenance
No Part No Description Req
1 1843
Decal - Warning, N.Z. only
1
9428
Decal - Electrical hazard,
Australia only
1
2 9208
Decal - Water
1
3 96924-9
Decal - Warning stripes
yellow/black
4m
4 0070901E
Decal - Serial number
1
5 9751
Decal - N.Z. made
1
6 12671
Decal - X33RT
2
11345-1
Decal - X27RT
2
7 12699
Decal - Rated load, X33RT
1
11346-1
Decal - Rated load, X27RT
1
8 0073298
Decal - Foam tyres
1
9 451986
Decal - Interlocks
2
10 476706
Decal - Explosive fumes
2
11 12574
Decal - Danger with alarm
1
12 569295
Decal - Snorkel logo
5
13 560240
Decal - Lower control box
1
14 12689
Decal - Upper control box
1
15 560272
Decal - Emergency stop upper
box
1
16 605726
Decal - Diesel fuel
1
17 12753
Decal - Emergency bleed
down
1
18 12814
Decal - Hydraulic fluid
1
19 58365-6
Decal - Safety prop
1
20 9223-3
Decal - Chevron
4
21 300699
Decal - Operators checklist
1
22 0323897
Decal - Must not operate
1
23 621486
Decal - Forklift
4
24 302950
Decal - Hydraulic oil level
1
No Part No Description Req
25 300700
Decal - Shearing hazard
1
26 12816
Decal - Emergency operation,
emergency lowering &
emergency pushing
1
27 0083427
Decal - Lifting/tie down
4
28 12815-4
Decal - Hydraulic circuit, RT
1
29 12815-2
Decal - Electrical circuit, RT
1
30 562426
Decal - Operators manual
enclosed
1
31 0372061
Decal - Torque wheel nuts
4
32 13182
Decal - www.snorkellift.com
2
■
Placards and Decals
Look to see that all plac ards and de cals are in place and leg i ble. Re place any miss ing or il leg i ble plac ards
or de cals be fore plac ing the RT into ser vice for the daily work shift.
De cal and plac ard kits for the RT are avail able from Snor kel deal ers.
❑ Standard placards and decals
●
See page 7 - 11 for the following items:
