PROGRAMMING MODE
http://www.miwiurmet.com.pl e-mail:miwi@miwiurmet.com.pl
12
P 0 X X
LU line configuration
0 0
Default settings restore.
001-009
Parameters (change only if it is necessary, always
consult with manufacturer first).
P 0 X X
Main setup
0 1
Edit and changing enter password.
0 2
Change the ID of call module.
0 3
Automatic user code confirmation.
0 4
Personal opening code using confirmation
0 5
Sound level of the keyboard.
0 6
Type of user codes.
0 7
General opening codes mode.
0 8
Individual opening codes mode.
0 9
Change function of the relay NC-C-NO with
electrical lock.
1 0
Voltage level of door phone line
P 2 x X
Time setting
0 1
Electrical lock- time of working.
0 2
Time of calling signal.
0 3
Pick up time.
0 4
Maximum time of conversation.
0 5
Relay activation time NC-C-NO.
P 3 X X
Data delete
0 1
Delete of all logical user codes SLAVE.
0 2
Deleting all individual opening codes.
0 3
Deleting all general opening codes.
0 4
Deleting all logical user codes MASTER.
0 5
Deleting all Dallas keys.
0 6
Deleting all digitiser data.
0 9
Deleting all data
P 4 X X
Defaults settings restore
0 1
Logical user codes restore. Top range limitted by
step 7.4 and 7.5.
0 2
Personal opening codes restore.
0 3
General opening codes restore.
0 4
All of data restore.
0 8
Eeprom memory deleting and reset
0 9
Default settings p.1, p.2 and p.7 restore.
P 5 X X
Logical user and opening codes
0 1
Logical user codes programming.
0 2
Re-mapping logical user codes.
0 3
Individual opening codes programming.
0 4
General opening codes programming.
0 5
Dallas key programming (associated dallas key to
user code )
0 6
Dallas key delete.
0 7
Dallas key identification.
P 6 X X
Service functions
0 1
Serial number of power supply.
0 2
Serial number of call module.
0 3
Measurement the current in riser 1.
0 4
Measurement the current in riser 2.
0 5
Power supply software version.
0 6
P 7 X X
Advanced functions
0 0
Keyboard backlight adjustment.
0 1
Switch on switchboard.
0 2
Programming number of keyboard uniting logical
entry EXI with EO of power supply in additional
channel.
0 3
Programming number of keyboard for EI terminal
in the power supply for
the additional
channel
0 4
Top range of user codes for riser 1.
0 5
Top range of user codes for riser 2.
0 6
Frequency of electric door lock mode.
0 7
Electric door lock- time of current DC.
0 8
Order House phones buttons.
0 9
Electrical door lock modes.
P 8 X X
MASTER/SLAVE functions
0
1
Change the ID of MASTER power supply.
0
2
Logical user codes programming for the main
channel.
0
3
Re-mapping logical user codes in the main
channel.
0 4
Programming number of keyboard uniting logical
entry EXI with EO of power supply in the main
channel.
0 5
Programming number of keyboard for EI terminal
in the power supply for
the main
channel
P 9 X X
Improvements functions
0 1
Deactivation “OFF” information.
0 2
Measurement the current in the door phone line
during conversation
0 3
PC connection configuration.
0 4
Communication mode in the main channel.
0 5
Communication mode in the additional channel.
0 6
Additional ring during pickup time
0 7
Automatic choosing of MASTER power supply.
0 8
Power supply reset.
0 9
Updating call module keyboard software.
PROGRAMING MODE FUNCTION
To choose relevant programming steps, please enter 2 associated
digits number and confirm by pressing the
#
button.
After enter to the right part of programming on the LED display
appears value of the parameter.
• Press
∗
∗∗
∗
button to back to main menu,
• Press
#
button to confirm parameter,
• Enter new parameter and press
#
button to confirm.
During the programming personal call users and opening codes
please hold the
#
button for about 1s.
To delete any personal call user or opening code please press and
hold
∗
∗∗
∗
key for about 1s
0. LU LINE CONFIGURATION
0.0 DEFAULT SETTINGS RESTORE
P
0
0
0
To activate this function press
#
button. During this process on
LED display will be shown this communication:
