2.3.3. Serial Package Methods
For network speed is faster than serial. Module will put serial data in buffer before sending it to network. The data
will be sent to Network as Package. There are 2 ways to end the package and send package to network - Time
Trigger Mode and Length Trigger Mode.
For example, set package time 10ms and package length 512, after serial port receiving data, if receiving interval
time beyond 10ms or data length beyond 512, data will be sent to network. One of package time or package length
is 0, N510 will adopt the method which is not 0. User can set package time and package length by setup software
or web server as follows:
Figure 17 Serial Package
