� The global only MAC address bought from IEEE, the user can define MAC address
(please state when you make order) .
� Support upgrade firmware via network.
� Support IP and domain name at the same time
� Support up to 4 link from client when act as TCP Server, send and receive data with
id.
� Can modify MAC address you wanted
� Can modify http server port for module built-in http server.
1.2.
1.2.
1.2.
1.2. Applications
Applications
Applications
Applications
� Fire and Security Panels
�
Vending Machines
� Point of Sale Terminals
� Remote equipment management
�
IT management services
� Access Control
� Industrial Control
�
Home Automation
� Instrumentation
� Building Control
�
Power Management
1.3.
1.3.
1.3.
1.3. Order
Order
Order
Order information
information
information
information
Type
Type
Type
Type Part
Part
Part
Part Numbers
Numbers
Numbers
Numbers Electric
Electric
Electric
Electric interface
interface
interface
interface
Serial to Ethernet Converter USR-TCP232- E 2 * TTL
Serial to Ethernet Converter USR-TCP232- 400 1 * RS232 , 1 * RS485 /RS422
Serial to Ethernet Converter USR-TCP232- 500 2 * RS232 , 1 * RS485 /RS422
Diagram 1 - 1 Order information
1.4.
1.4.
1.4.
1.4. Electrical
Electrical
Electrical
Electrical c
c
c
c haracteristics
haracteristics
haracteristics
haracteristics
DC Power Supply Voltage :
Two DC Voltage can be choose （ for USR-TCP232-E, others see Hard interface ）
VCC ： type: 3.3V, min: 3.15 ， max: 3.45 V
VDD ： type: 5V, min: 4.5V ， max: 5.5V
Operating supply current : Max: 180 MA
Operating Temperature : 0~75 ° C (business version) - 25-80 ° C (industry version)
Storage temperature : -40~85 ° C
