THERMOSTATINSTALLATION

Optionalthermostatsareavailableforusewithyourpelletstove.Athermostatcanhelpyoumaintainaconstant
roomtemperature.Thethermostatoptionwillrequiretheins tallationofamillivolttypethermostat.

NOTE:Yourthermostatshouldbeinstalledbyanauthorizeddealerorserviceperson.

InstallationofRemoteThermostat:
 DisconnectPelletStoveRoomHeaterunitfrompowersupply.
 Openrightsidepaneltogainaccesstorearofcontrolpanel.
 Stripinsulationfromthermostatwiresandconnecttothescrewterminalontherearofthecontrolpanel(see
Figure4).

If you have installed a remote
 thermostat for your pellet stove and wish to have the heater controlled by that
thermostat,depresstheMODEbuttontoengageT‐STATmode.Thethermostatwillcontroltheheatoutputofthe
heateralternatingbetweenthelowestheatlevelandthehighestheatlevelthatyouhavepre‐selected.

TheT‐STATmodeprovidesthemostevenheatoutput,forbettercomfort,andtoextendthelifeofthepelletfuel
ignitionsystem.Additionally,theconstantflameservesasawarningfor peopleandpetstokeepawayfromthe
heaterwhileitisinoperation.






Left:GND
Middle:Thermostat
Right:5Vpowersource
