USSC 5660 - Maintenance; Burn Pot Care

30
MAINTENANCE
FAILURETOCLEANANDMAINTAINTHISUNITASINDICATEDMAYRESULTINPOORPERFORMANCE
ANDHAZARDOUSSITUATIONS.CLEANTHEHEATERFREQUENTLYASACCUMULATIONOFSOOT,
CREOSOTEORFLYASHMAYOCCUR.NEVERCLEANTHEUNITWHENHOT.
BurnPot:
Note:Lettheunit coolto roomtemperaturebeforeinspectingtheburnpot.Inspecttheburn potregularly to
checkthattheholeshavenotbecomeplugged.Ifnecessarycleanthoroughly.Itisimperativethattheburnpot
bere‐installedthecorrectwayortheunitwillnotlight.The
endoftheburnpotwithanigniterholeinit(see
Figure23)mustbeinstalledfacingtherearoftheunit.Thisholeallowstheignitertoheatupthepelletstothe
pointofignition.













Figure23
Figure24
