2NM/2NX/2NY/2NZ/2P0/2P6
1-4-3
List of JAM Code
Code Contents Conditions
Jam
location*
0000 Initial jam The power is turned on when a sensor in the con-
veying system is on.
-
0100 Secondary feeding timeout Secondary paper feed request given by the con-
troller is unreachable.
H
0101 Wait for ready of print-process
package
Process package won’t become ready. H
0104 Wait for ready of conveying
package
Conveying package won’t become ready. H
0105 Driving prevention A drive does not stop. H
0106 Paper feeding request for
duplex printing time out
Paper feeding request for duplex printing given by
the controller is unreachable.
I
0107 Wait for ready of fuser pack-
age
Fuser package won’t become ready. H
0110 Rear cover open The rear cover is opened during printing. -
0111 Top cover open The top cover is opened during printing. -
0120 Receiving a duplex paper
feeding request while paper is
empty
Paper feed request was received from the duplex
section despite the absence of paper in the
duplex section.
I
0121 Exceeding number of duplex
pages circulated
The controller issued the duplex section a request
for more pages than the duplex print cycle con-
tains.
I
0501 No paper feed jam The registration sensor 1 (RS1)*1 or sensor 3
(RS3)*2 does not turn on during paper feed from
cassette 1.
1
0502 PF feed sensor 1 (PFFS1) does not turn on dur-
ing paper feed from cassette 2.
2
0503 PF feed sensor 2 (PFFS2) does not turn on dur-
ing paper feed from cassette 3.
3
0504 PF feed sensor 3 (PFFS3) does not turn on dur-
ing paper feed from cassette 4.
4
0505 PF feed sensor 4 (PFFS4) does not turn on dur-
ing paper feed from cassette 5.
5
0508 The registration sensor 1 (RS1)*1 or sensor 3
(RS3)*2 does not turn on during paper feed from
duplex section.
I
0509 The registration sensor 1 (RS1)*1 or sensor 3
(RS3)*2 does not turn on during paper feed from
MP tray.
B
To Next Page
