(4) Installing the IC card reader holder (HyPAS model only)
IC card reader holder installation requires the following parts):
Supplied parts of IC card reader holder 10 (1702P60UN1):
Procedure
1. Mount the IC card reader to the IC card
reader holder.
Figure 1-2-37
Parts Quantity Part.No.
IC card reader holder 10 1 1702P60UN1
Parts Quantity Part.No.
IC card reader holder 1 -
Label 1 -
M3 ×8 bind screw 1 -
IC card reader
IC card reader holder
To Next Page
