Utax P-4030 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-53
(3) Connector lists
Connector Pin Signal I/O Voltage Description
YC2
1 GND - - Ground
Connected to
the LCD
2 R0 O 0/3.3 V DC LCD Control signal
3 R1 O 0/3.3 V DC LCD Control signal
4 R2 O 0/3.3 V DC LCD Control signal
5 R3 O 0/3.3 V DC LCD Control signal
6 R4 O 0/3.3 V DC LCD Control signal
7 R5 O 0/3.3 V DC LCD Control signal
8 GND - - Ground
9 G0 O 0/3.3 V DC LCD Control signal
10 G1 O 0/3.3 V DC LCD Control signal
11 G2 O 0/3.3 V DC LCD Control signal
12 G3 O 0/3.3 V DC LCD Control signal
13 G4 O 0/3.3 V DC LCD Control signal
14 G5 O 0/3.3 V DC LCD Control signal
15 GND - - Ground
16 B0 O 0/3.3 V DC LCD Control signal
17 B1 O 0/3.3 V DC LCD Control signal
18 B2 O 0/3.3 V DC LCD Control signal
19 B3 O 0/3.3 V DC LCD Control signal
20 B4 O 0/3.3 V DC LCD Control signal
21 B5 O 0/3.3 V DC LCD Control signal
22 GND - - Ground
23 DCLK O 0/3.3 V DC LCD dot clock signal
24 3.3V O 3.3V DC 3.3 V DC power output
25 3.3V O 3.3V DC 3.3 V DC power output
26 3.3V O 3.3V DC 3.3 V DC power output
27 3.3V O 3.3V DC 3.3 V DC power output
28 DE O 0/3.3 V DC(pulse) LCD data enabling signal
29 HSYNC O 0/3.3 V DC(pulse) Horizontal synchronizing signal
30 VSYNC O 0/3.3 V DC(pulse) Vertical synchronizing signal
31 LED_EN O 0/3.3 V DC Backlight LED enabling signal
32 LED_PWM O 0/3.3 V DC Backlight LED control signal
33 TSC_INT - - Not used
34 I2C_SDA - - Not used
35 I2C_SCL - - Not used

Utax P-4030 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Maximum scan area	A4 (210 x 297) mm
Scan speed (color)	30 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	17 ppm
Duplex scan speed (color)	13 ppm
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3
Cabling technology	10/100/1000Base-T(X)
Authentication method	SMTP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	667 MHz
Paper input type	Cassette
Total input capacity	500 sheets
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Standard interfaces	Ethernet, USB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	2.6 W
Power consumption (standby)	53.7 W
Power consumption (average operating)	679 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
