Utax P-4030 MFP

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-5-99
(5) Direction of installing the principal fan motors
When detaching or refitting the fan moter,be careful of the airflow direction (intake or exhaust).
Figure 1-5-170
LSU fan motor
(Rating label: inside)
Intake
Intake
Intake
Developer fan motor
(Rating label: inside)
Powersource fan motor
(Rating label: inside)
