Utax P-4030 MFP

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-23
14. Remove two screws.
(50/60 ppm model only)
(1)Slide the right inner spacer and the left
inner spacer forward and then remove it
upward.
Figure 2-2-21
15. Remove two screws.
16. Remove the center stay cover.
Figure 2-2-22
Screw
Screw
Right inner
spacer
Left inner
spacer
Screw
Screw
Eject unit cover
