Utax P-4030 MFP

2NM/2NX/2NY/2NZ/2P0/2P6
2-2-45
43. Remove the screw.
44. Pull two connectors out and then
remove the high voltage PWB.
45. Check or replace the high voltage PWB
and refit all the removed parts.
Figure 2-2-55
High voltage PWB
Connector
Connector
Screw
