Utax P-4030 MFP Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
2-3-21
No.3
USB
HOST
Ethernet/
USB
DEVICE
RJ45
CONPWB
DIMM
SD CARD
eKUIO1
eKUIO0
YC2002
YC2003
WETCLK GND AIRWET AIRTEMP
YC30
4 3 2 1
YC2010
YC2009
YC2004
YC2012
YC2013
YC2000
YS2000
Flash
writer
YC2005
USB
Mini B
YC2011
Micro
USB
YC2011
Debagger
YC2007
YC1002
M LED C GND HP SWN +3.3V3 E1 N.C. GND CCDRS- CCDRS+ GND CCDCP+ CCDCP - GND CCDPH1 - CCDPH1+ GND GND CCDSH CCDSW GND CCDOSB(ODD) GND CCDOSG(EVEN) GND CCDOSR GND N.C. +5V3 E3 +5V3 E3 N.C. 12V3 E2 12V3 E2
YC1003
DPOS
DPOCS
DPSBS
LEDPWB
2
1
2
1
1 2 3
USB
Mini B
DPTS
YC2008
Debugger
YC2006
(PPC)
(ARM)
+5V5
BLIGHT
OPPWB
BUZZER
YC1
TEMP SENSER
HUMIDITY SENSOR
1
2
1
2
BLPWB
RD
BK
YC2
1 2 3 4
YC3YC4
1 2 3 4
+3.3V3S GND SET_SW +3.3V3S GND REGIST_SW +3.3V3S GND DP_OPEN_SW +3.3V3S GND JHP_SW +3.3V3S GND TIMING_SW
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
3 2 1
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
1 2 3 4
1 2 3 4
USB HOST
(2NZ)
1 2
SPK
1 2
1
2
1
2
LED_Anode
LED_Cathode
SCMOTB2 SCMOTA1 SCMOTB1 SCMOTA2
1 2 3 4
ISUM
YELLOW BLACK ORANGE BROWN
YC1000
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
32 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
9 8 7 6 5 4 3 2 1
10
9 8 7 6 5 4 3 2 1
10
9 8 7 6 5 4 3 2 1
GND INT_POWERKEY FPRST AUDIO PAN_TXD PAN_RXD 5.0V2_C LCDCON 3.3V1_C GND
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15
1 2
3 4 5 6 7 8 9
10 11 12 13 14 15
GND - INT_POWERKEY FPRST AUDIO - PAN_TXD PAN_RXD - - 5.0V2_C - LCDCON 3.3V1_C GND
YC1001
CONNMOTB2 CONNMOTB1 CONNMOTA2 CONNMOTA1 JNCMOTB2 JNCMOTA2 JNCMO TB1 JNCMOTA1 FEEDMOTB2 FEEDMOTB1 FEEDMOTA2 FEEDMOTA1
1 2 3 4 5 6 7 8 9
10 11 12
6 4 3 1
6 4 3 1
DPCM
4 3 2 1
4 3 2 1
DPSBM
6 4 3 1
6 4 3 1
DPPFM
1 2 3 4 5 6 7 8 9
10 11 12
DPRS
CCDPWB
YC3
YC1
YC2
HPS
3 2 1
3 2 1
1 2 3
+3.3V3S GND HP_SWN
(FRONT)
LCD
SPK+ SPK-

Utax P-4030 MFP Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Copier resize	25 - 400 %
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	40 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Maximum scan area	A4 (210 x 297) mm
Scan speed (color)	30 ppm
Image formats supported	JPG, TIF
Duplex scan speed (black)	17 ppm
Duplex scan speed (color)	13 ppm
Document formats supported	PDF, XPS
Faxing	No
Digital sender	-
Printing colors	Black
Maximum duty cycle	- pages per month
Page description languages	Epson LQ, IBM ProPrinter, PCL 5c, PCL 5e, PCL 6, PCL XL, PDF 1.7, PostScript 3
Cabling technology	10/100/1000Base-T(X)
Authentication method	SMTP
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Supported network protocols (IPv4)	TCP/IP
Internal memory	512 MB
Processor model	465S
Processor family	PowerPC
Processor frequency	667 MHz
Paper input type	Cassette
Total input capacity	500 sheets
Total output capacity	250 sheets
Multi-Purpose tray input capacity	100 sheets
Duplex media weight	60 - 120 g/m²
Paper tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Product color	Black, Grey
Market positioning	Business
Standard interfaces	Ethernet, USB
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Power consumption (off)	2.6 W
Power consumption (standby)	53.7 W
Power consumption (average operating)	679 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Server operating systems supported	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012 R2
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
Weight	21500 g
