2NM/2NX/2NY/2NZ/2P0/2P6-6
1-3-16
(50) Left offset for each paper source
MP tray/Paper feeder 1/Paper feeder 2/
Paper feeder 3/Paper feeder 4/Duplex/Page rotation
(51) L value settings
Top margin integer part / Top margin decimal part/
Left margin integer part / Left margin decimal part/
(52)
Life counter (The first line) Machine life/MP tray/Cassette/Paper feeder 1/
Paper feeder 2 /Paper feeder 3/Paper feeder 4/Duplex
Life counter (The second line) Drum unit K/Developing unit K/
Maintenance kit
(53) Panel lock information 0: OFF/1: Partial lock/2: Full lock
(54) USB information U00: Not installed/U01: Full speed/U02: Hi speed
(55) Paper handling information 0: Paper source unit select/1: Paper source unit
(56) Auto cassette change 0: OFF/ 1: ON
(57) Black and white printing double count
mode
0: All single counts
1: A3, Single count, Less than 420 mm (length)
2: Legal, Single count, 356 mm or less (length)
3: Folio, Single count, Less than 330 mm (length)
(58) Billing counting timing -
(59) Temperature (machine outside) -
(60) Relative humidity
(machine outside)
-
(61) Fixed assets number -
(62) Job end judgment time-out time -
(63) Job end detection mode -
(64) Prescribe environment reset
0: Off
1: On
(65) Media type attributes
1 to 28 (Not used: 18, 19, 20)
* : For details on settings, refer to
“Prescribe Commands Refer-
ence Manual.
Weight settings Fuser settings
0: Light 0: High
1: Normal 1 1: Middle
2: Normal 2 2: Low
3: Normal 3 3: Vellum
4: Heavy 1 Duplex settings
5: Heavy 2 0: Disable
6: Heavy 3 1: Enable
7: Extra Heavy
(66) RFID information -
(67)
Soft version of the optional paper
feeder
Paper feeder 1/Paper feeder 2/Paper feeder 3
Paper feeder 4
(68) Version of the optional message -
(69) Maintenance information -
(70) Altitude 0: Standard
1: High altitude 1
2: High altitude 2
(71) Charger roller correction 1 to 5
No. Description Supplement
