Status Menu
6-2
Displaying the Status Menu Screen
If Status is displayed at the left of the bottom row of the message display
whilst the machine is printing or awaiting printing, it is possible to display
the Status menu screen.
Press [Status] ([Left Select]). The Status menu screen appears.
The following operations are possible on the Status menu screen:
• Job Status...6-3
• Job Log...6-4
• USB Keyboard...6-5
• Network...6-5
• Wi-Fi...6-6
• Wi-Fi Direct...6-6
• Option Network...6-8
Ready to print.
A4 A4
Status
Toner
Status:
Network
Exit
03
Job Log
02
01
Job Status
Note USB Keyboard is only displayed when a USB keyboard is
connected.
Wi-Fi and Wi-Fi Direct are only displayed when the optional
Wireless Network Interface Kit (IB-36) is installed.
Option Network is only displayed when the optional Network
Interface Kit (IB-50) or Wireless Network Interface Kit (IB-51) is
installed.
To Next Page
