Preparation before Use
2-44
Loading Envelopes
5 envelopes may be loaded in the multi purpose tray.
Acceptable envelope sizes are as follows.
When you load envelopes or Hagaki (cardstock) in the multi purpose tray
Load envelope with the print side facing up. For the procedure for printing, refer to the Printing System Driver User Guide.
When you load envelopes in the bulk feeder
You can load envelopes in the bulk feeder (PF-3100). How to load envelopes (orientation and facing) is same as that of
loading in the multi purpose tray.
Acceptable Envelope Size
Youkei 2 114 × 162 (mm)
Youkei 4 105 × 235 (mm)
Envelope Monarch 3 7/8" × 7 1/2"
Envelope #10 4 1/8" × 9 1/2"
Envelope DL 110 × 220 (mm)
Envelope C5 162 × 229 (mm)
Executive 7 1/4" × 10 1/2"
Envelope #9 3 7/8" × 8 7/8"
Envelope #6 3 5/8" × 6 1/2"
Oufukuhagaki
(Return postcard)
Portrait form
envelopes
Landscape form
envelopes
Close
the flap.
Hagaki
(Cardstock)
Open
the flap.
IMPORTANT Use unfolded Oufukuhagaki (return postcard).
How to load envelopes (orientation and facing) will differ depending on the type of envelope. Be sure to load it in
correctly, otherwise printing may be done in the wrong direction or on the wrong face.
Note When you load envelopes in the multi purpose tray, select the envelope type by referring to Media Type
(Paper type setting for the MP tray) on page 4-31.
