Chapter 1: Reporting codes
6 NX-8E Control Panel Installation Manual
Terminal
Description
RELAY2
C = Closed dry contact rated 1 amp at 30 volts.
NO = Normally open dry contact rated 1 amp at 30 volts.
Note: These terminals can be set for 12 VDC. Install J12 for AUX1 and J13 for
AUX2.
COM
Common used to ground any devices connected to relays
RELAY1
NC = Normally closed dry contract rated 1 amp at 30 volts.
C = Closed dry contact rated 1 amp at 30 volts.
Note: These terminals can be set for 12 VDC. Install J12 for AUX1 and J13 for
AUX2.
Module list
Table 3 below shows some of the modules that are compatible with the NX-8E
system. Additional information is available from customer support.
Table 3: Module list
Part number
Description
NX-8E
NX-8E control only.
NX-848-KIT
NX-8E control, NX-148 LED keypad, 16.5 V 40 VA transformer.
NX-108E
8-zone LED keypad.
NX-116E
16-zone LED keypad.
NX-124E
24-zone LED keypad.
NX-148E
Alphanumeric 48-zone LCD keypad.
NX-200
Zone doubling kit (includes one hundred 3.74k and one hundred 6.98k
resistors).
NX-216E
16-zone expander module
NX-320E
Smart power supply and bus extender.
NX-408E
8-zone wireless expansion module.
NX-416E
16-zone wireless expansion module.
NX-448E
48-zone wireless expansion module.
NX-507E
7-relay output module.
NX-508E
8-output module.
NX-534E
Two-way listen-in module.
NX-540E
Operator telephone interface module.
