Appendix A: Reporting codes
72 NX-8E Control Panel Installation Manual
Keypad
number
Partition
1
2
3
4
5
6
7
8
4
216
217
218
219
220
221
222
223
5
224
225
226
227
228
229
230
231
6
232
233
234
235
236
237
238
239
7
240
241
242
243
244
245
246
247
8
248
249
250
251
252
253
254
255
Zone ID or user ID hex digit for 4+2 formats
Zone or user ID hex digits only apply to slow formats (Locations 56 to 83, lower
digit). The digits programmed in these locations are sent as the upper hex digit in
place of the alarm event code. The zone ID or user ID are always reported as the
lower hex digits. The following table shows the hex digit for the zone/user IDs.
For example, if the zone/user ID is 15, the 4+2 lower digit is F.
Table 18: Zone/user ID and hex digit
Zone/user ID = Hex digit
Zone/user ID = Hex digit
Zone/ID = Hex digit
1 = 1
2 = 2
3 = 3
4 = 4
5 = 5
6 = 6
7 = 7
8 = 8
9 = 9
10 = A
11 = B
12 = C
13 = D
14 = E
15 = F
16 = 1
17 = 2
18 = 3
19 = 4
20 = 5
21 = 6
22 = 7
23 = 8
24 = 9
25 = A
26 = B
27 = C
28 = D
29 = E
30 = F
31 = 1
32 = 2
33 = 3
34 = 4
35 = 5
36 = 6
37 = 7
38 = 8
39 = 9
40 = A
41 = B
42 = C
43 = D
44 = E
45 = F
46 = 1
47 = 2
48 = 3
49 = 4
50 = 5
51 = 6
