Appendix B: Reporting codes
76 NX-8E Control Panel Installation Manual
Programming worksheet
Use the following worksheet to check location defaults and record location
settings. Locations with multiple segments will show defaults as multiple numbers
separated by commas. Defaults are shown in bold.
Table 19: Location defaults and settings
Loc.
Description
Default
Setting
0
Phone 1 (20 segments)
14 (each segment)
1
Phone 1 account code
10, 10, 10, 10, 10, 10
2
Phone 1 communicator format
0
3
Phone 1 dial attempts
Backup control
8
0
4
Phone 1 events reported
Segment 1
1 = Alarms and restores
2 = Open/close
3 = Bypass
4 = Zone trouble
5 = Power trouble
6 = Siren and telephone fault
7 = Test reports
8 = Program, download and log full
Segment 2
1 - Tampers
2 = Short circuit and ground fault
3 = Sensor lost
4 = Sensor low battery
5 = Expander trouble
6 = Failure to communicate
7 = Zone activity monitor
8 = Reserved
5
Partitions reported to phone 1
Segment 1 = Partitions 1 to 8
1
2
3
4
5
6
7
8
6
Phone 2 (20 segments)
14 (each segment)
7
Phone 2 account code
10, 10, 10, 10, 10, 10
8
Phone 2 communicator format
0
9
Phone 2 dial attempts
Backup control
8
0
10
Phone 2 events reported
Segment 1
1 = Alarms and restores
2 = Open/close
3 = Bypass
4 = Zone trouble
5 = Pow er trouble
6 = Siren and telephone fault
7 = Test reports
8 = Program, dow nload and log full
Segment 2
1 - Tampers
2 = Short circuit and ground fault
3 = Sensor lost
4 = Sensor low battery
5 = Expander trouble
6 = Failure to communicate
7 = Zone activity monitor
8 = Reserved
11
Partition reported to phone 2
Segment 1 = Partitions 1 to 8
1
2
3
4
5
6
7
8
12
Phone 3 (20 segments)
14 (each segment)
