Chapter 2: Reporting codes
28 NX-8E Control Panel Installation Manual
Locations 23 and 24 - Partition features
Location 23 - Feature report selection/partition feature selection
Location 23 has five segments of feature selection data. Use this location to
enable certain features that are accessed or visible to the user from the system
keypad. In addition, you can enable certain communicator reports in this location.
Segment 1
1. On enables quick arm.
2. On enables re-exit.
3. On enables automatic bypass.
4. On enables silent keypad panic (overrides the audible panic selection).
5. On enables audible keypad panic.
6. On enables keypad aux 1 (fire panic).
7. On enables keypad aux 2 (emergency panic).
8. On enables keypad multiple code attempt tamper.
Segment 2
1. On enables LED extinguish.
2. On enables require code for bypassing.
3. On enables zone bypassed sounder alert.
4. On enables AC power/low battery sounder alert.
5. On enables bypass toggle.
6. On enables silent autoarm.
7. On enables automatic instant.
8. On enables instant mode toggle.
Segment 3
1. On enables opening and closing reporting.
2. On enables zone bypass reporting.
3. On enables zone restore reporting.
4. On enables zone trouble reporting.
5. On enables zone tamper reporting.
6. On enables cancel reporting.
7. On enables recent closing reporting.
8. On enables exit error reporting.
Segment 4
1. Enables late to close/early to open reporting.
2. On enables autoarm in stay mode.
3. On disables door delays in night mode (applies to NX-1208E/NX1248E keypads).
4 to 8. Reserved.
