Chapter 2: Reporting codes
34 NX-8E Control Panel Installation Manual
Location 37 - Siren and system supervision
Location 37 has seven segments of feature selection data. Use this location to
enable various system feature and reporting options.
Segment 1
1. On if siren sounds for telephone line cut when armed.
2. On if siren sounds for telephone line cut when disarmed.
3. On if siren blast at arming.
4. On if siren blast at exit expiration.
5. On if siren blast at closing kissoff.
6. On if siren sounds during a cross zone verification time.
7. On if siren sounds for a zone or box tamper.
8. On if siren blasts one time for keyswitch or wireless arming; two times for disarming (must be
disabled for SIA CP-01). Siren will blast four times when disarmed if there is an alarm in
memory.
Segment 2
1. On if siren driver should be a voltage output; off if on board siren driver is enabled.
2. On if siren sounds for expander trouble.
3. On for immediate restore by zone; off for zones to restore when the siren times out.
4. On if dynamic battery test performed at arming; off if performed at disarming.
5. On if battery missing test is done every 12 seconds, otherwise panel tests at midnight.
6. On if manual bell test is done during *-4-4 test function.
7. On if manual communicator test is done during *-4-4 test function.
8. On enables box tamper terminals on the panel.
Segment 3
1. On enables box tamper report.
2. On enables AC fail reporting.
3. On enables low battery reporting.
4. On enables auxiliary power overcurrent report.
5. On enables siren supervision report.
6. On enables telephone line cut report.
7. On enables ground fault detection report.
8. On enables expander trouble report.
Segment 4
1. On enables fail to communicate report.
2. On enables log full report.
3. On enables autotest report.
4. On enables start/end programming report.
5. On enables end download report.
6. On enables low battery report.
7. On enables sensor missing report.
8. On enables first to open/last to close report.
Segment 5
1. On enables lost clock service light
2. On enables zone doubling (requires NX-200 zone doubling kit).
3. On disables on board 8 zones.
