Chapter 2: Reporting codes
NX-8E Control Panel Installation Manual 19
Caution: A call-waiting cancel on a non call-waiting line prevents successful
connection to the central station.
Location 1 Phone 1 account code
Location 1 has six segments of numerical data. Use this location to program the
account code sent when phone 1 is dialed. The default for each segment is 10.
Program a 10 in the segment immediately after the last digit of the account code.
If the account code is six digits long, program all six segments.
Location 2 - Phone 1 communicator format
Location 2 has one segment of numerical data. Use this location to program the
communicator format used to transmit to the receiver connected to phone 1.
Refer to your central station receiver documentation to determine which format is
compatible. Table 6 below describes the formats for this location. If you need a
format other than those listed, review the override options described in Location
18. Program a 15 to create a special format (in addition to the entries in Location
18). The default is 0. If this location contains a 0, the built-in communicator is
disabled and the NX-8E functions as a local-only control.
Table 6: Communicator formats
Data
Format
Description
0
Local
Communicator is disabled.
1
Universal 4+2
Two-digit event code 1800 Hz transmit 2300 Hz handshake double
round parity 40 pulses per second (pps)
2
3+1 fast (or 4+1)
One-digit event code 1900 Hz transmit 1400 Hz handshake double
round parity 20 pps.
3
Reserved
Reserved
4
Pager
Two-digit event code DTMF transmission.
5
3/1 or 4/1 slow
1800 Hz transmit 2300 Hz handshake double round parity 20 pps hex
capability.
6
3/1 or 4/1 slow
1800 Hz transmit 1400 Hz handshake double round parity 20 pps hex
capability.
7
3/1 or 4/1 fast
1800 Hz transmit 2300 Hz handshake double round parity 40 pps hex
capability.
8
3/1 or 4/1 fast
1800 Hz transmit 1400 Hz handshake double round parity 40 pps hex
capability.
9
3/1 or 4/1 fast with
parity
1800 Hz transmit 2300 Hz handshake single round parity 40 pps hex
capability.
10
3/1 or 4/1 fast with
parity
1800 Hz transmit 1400 Hz handshake single round parity 40 pps hex
capability.
