Appendix B: Reporting codes
78 NX-8E Control Panel Installation Manual
Loc.
Description
Default
Setting
Segment 3
1 = Open/close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent closing
8 = Exit error
Segment 4
1 = Late to close/early to open
2 = Auto arm in stay mode
3 = Disables door delays in night mode
4 = Bypass disabled for force arm zones
5 to 8 = Reserved
Segment 5 (Reserved)
24
Entry/exit times)
Segment 1 = Entry time 1
30
Segment 2 = Exit time 1
60
Segment 3 = Entry time 2
30
Segment 4 = Exit time 2
60
Segment 5 and 6 = Reserved
25
Zones 1 to 8 zone types
3, 5, 6, 6, 6, 6, 6, 6
26
Zones 1 to 8 partitions
Segment 1 = 1 2 3 4 5 6 7 8
Segment 2 = 1 2 3 4 5 6 7 8
Segment 3 = 1 2 3 4 5 6 7 8
Segment 4 = 1 2 3 4 5 6 7 8
Segment 5 = 1 2 3 4 5 6 7 8
Segment 6 = 1 2 3 4 5 6 7 8
Segment 7 = 1 2 3 4 5 6 7 8
Segment 8 = 1 2 3 4 5 6 7 8
27
Zones 9 to 16 zone types
6, 6, 6, 6, 6, 6, 6, 6
28
Zones 9 to 16 partitions
Segment 1 = 1 2 3 4 5 6 7 8
Segment 2 = 1 2 3 4 5 6 7 8
Segment 3 = 1 2 3 4 5 6 7 8
Segment 4 = 1 2 3 4 5 6 7 8
Segment 5 = 1 2 3 4 5 6 7 8
Segment 6 = 1 2 3 4 5 6 7 8
Segment 7 = 1 2 3 4 5 6 7 8
Segment 8 = 1 2 3 4 5 6 7 8
29
Zones 17 to 24 zone types
6, 6, 6, 6, 6, 6, 6, 6
30
Zones 17 to 24 partitions
Segment 1 = 1 2 3 4 5 6 7 8
Segment 2 = 1 2 3 4 5 6 7 8
Segment 3 = 1 2 3 4 5 6 7 8
Segment 4 = 1 2 3 4 5 6 7 8
Segment 5 = 1 2 3 4 5 6 7 8
Segment 6 = 1 2 3 4 5 6 7 8
Segment 7 = 1 2 3 4 5 6 7 8
Segment 8 = 1 2 3 4 5 6 7 8
31
Zones 25 to 32 zones types
6, 6, 6, 6, 6, 6, 6, 6
32
Zones 25 to 32 partitions
Segment 1 = 1 2 3 4 5 6 7 8
Segment 2 = 1 2 3 4 5 6 7 8
Segment 3 = 1 2 3 4 5 6 7 8
Segment 4 = 1 2 3 4 5 6 7 8
Segment 5 = 1 2 3 4 5 6 7 8
Segment 6 = 1 2 3 4 5 6 7 8
Segment 7 = 1 2 3 4 5 6 7 8
Segment 8 = 1 2 3 4 5 6 7 8
33
Zones 33 to 40 zone types
6, 6, 6, 6, 6, 6, 6, 6
