PAGE 25
FIGURE 25
PEG-C REPLACEMENT PARTS - ELECTRICAL
ITEM PART
NUMBER NUMBER DESCRIPTION OTY.
1 EF-013.01 ELEC. J-BOX 4X4X1/2 2
2 37414401 WIRE PRES. SWITCH TO J-BOX 34" 1
3 37424501 HARNESS-ELWCO TO J-BOX 18" 1
4 PB00702 IGN WIRE 30" CIDE MODELS ONLY 1
5 37413602 HARNESS IGN. MOD. TO GAS VALVE 12" 1
6 PB00604 SPK CTL S8600M1013 1
7 37413201 WIRE SPILL SWITCH 47" 1
8 37413801 WIRE J-BOX TO CONTROLS 27" 1
9 EF03601 WIRE CLAMP #3600 WHITE 1
10 37413002 WIRE TRANSFORMER (WHITE) 15" 1
11 37413001 WIRE TRANSFORMER (BROWN) 15" 1
12 3641601 TRANSFORMER ASSEMBLY 24V 1
13 37413101 DAMPER CABLE 53" 1
14 3641501 ELEC 4"X4" COVER/TERM STRIP 1
