Utilitech 148012 - House Plumbing Connection

11
Glue
1 in. Pipe
3
IL1366
Glue
Elbow
2
IL1365
Glue
Adapter
Pipe
1
3. Attach a 1 in. pipe (not included) to the elbow
and a 1 in. x 3/4 in. reducer bushing (not
included) to the pipe.
2. Attach a 1 in. elbow (not included) to the pipe.
1. Most pressure tanks will have a 1 in. inlet
elbow on the bottom. Connect to this elbow
with a 1 in. MPT x 1 in. slip (glue) adapter and
short piece of pipe.
TANK TO HOUSE CONNECTION
