4
PREPARATION
Estimated Installation Time: 20 minutes
Materials required for assembly: Sump basin, inlet piping, discharge piping (PVC, poly pipe or
galvanized steel), check valve, and 2-step PVC glue system (primer and sealer).
GENERAL PUMP INFORMATION
This pump is designed to be installed in a sump basin for removing clear drain water and will usually
pass small particles suspended in water. Heavy mud, sand, or pea gravel can clog the pump, which
can usually be cleaned out by back-ushing with a garden hose through the pump discharge.
A check valve must be installed in the discharge pipe to keep water from draining back into the sump
basin when it is not operating. The sump basin must be at least 18 in. deep and 12 in. in diameter.
NOTES: Before installing pump:
• Have the electrical circuit checked by an electrician to ensure proper grounding.
• Connect pump to a grounded circuit equipped with a ground fault circuit interruptor (GFCI) device.
• BE CERTAIN the pump power source is disconnected before installing or servicing this unit.
• Be sure the sump basin and piping are clear of sand, dirt and scale. Debris will clog pump and
void warranty.
• Failure to protect pump and piping from freezing could cause severe damage and will void the
warranty.
• Do not run pump dry.
SPECIFICATIONS
MODEL HP AMPS
PERFORMANCE IN GALLONS PER MINUTE
0 FT. 5 FT. 10 FT. 15 FT.
1964546 1/3 3.5 58 50 36 10
