V2 CITY2+ - Page 25

ENGLISH
51
CITY2+ FUNCTION TABLE
DISPLAY DATA DESCRIPTION DEFAULT
MEMO
DATA
LUCi Courtesy lights CiCL
t.LUC - Timed operation (from 0 to 20 min)
no - Function disabled
CiCL - On for the entire cycle duration
AUS Auxiliary channel Mon
tiM - Timed operation (from 0 to 20 s)
biSt - Bistable operation
Mon - Monostable operation
SPiA Low Voltage Output Setup no
no - Not used
FLSh - Flashing light operation
W.L. - Indicator light operation
LP.PA no / Si Flasher in pause no
Strt START Input
no - Inputs from terminal strip disabled
StAn - Standard operation
AP.CH - Separate open and close commands
PrES - Manned operation
oroL - Timer Operation
StoP STOP Input no
no - The input is disabled: the STOP command is not received
invE - The STOP command stops the gate: The next START inverts the direction
ProS - The STOP command stops the gate: The next START does not invert the direction
Fot 1 PHOTO 1 Input no
APCh - Acts like active photocell on open and close
no - Disabled
Fot 2 PHOTO 2 Input CHCh
CFCh - Acts like active photocell on close and with gate stopped
no - Disabled
Ch - Functions like active photocell only on close
Ft.tE no / Si Photocells test no
CoS1 Safety device 1 input (stationary safety device) no
no - Input not enabled
AP - Input active only on open
APCH - Input active on open and close
CoS2 Safety device 2 input (mobile safety device) no
no - Input not enabled
CH - Input active only on close
APCH - Input active on open and close
Co.tE Operational test of safety devices no
no - Test disabled
Foto - Test enabled for optical safety devices
rESi - Test enabled for resistive rubber safety devices
FC.En no / Si Limit switch inputs no
EnCo no / Si Encoder Input no
ASM 0.5” ÷ 3.0” Anti-skid no
no - Function disabled
FinE End of programming no
no - Do not exit programming menu.
Si - Exit from programming menu and save the parameters set.
