vacon • 6 UK: VACON
®
100 drive supply switch
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
10
The data cable installation
in MR4 seen from above.
11
Close the cover of the
drive.
S
D
M
2T1
4T2
6T3
1L1
3L2
5L3
