Vacon 100 Series User Manual

11
THE CABLE AND FUSE SIZES FOR VACON
®
100 FAMILY
IN NORTH AMERICA, MAINS VOLTAGE 525600 V
* = If you use a multi-conductor cable, 1 of the conductors of the brake resistor cable stays unconnected.
It is also possible to use a single cable if you obey the minimum cross-sectional area of the cable.
Enclosure
size
Type IL [A]
Fuse
(class T)
[A]
Mains, motor and
brake resistor*
cable (Cu) [AWG]
Terminal cable size
Mains cable
terminal
[AWG/kcmil]
Ground terminal
[AWG/kcmil]
MR9
0144 6 / 0144 7 144.0 175 3/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0170 7 170.0 200 4/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0208 6 / 0208 7 208.0 250 300 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR10
0261 7 261.0 350 2xAWG2/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0325 7 325.0 450 2x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0385 7 385.0 500 2x250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil 0416 7 416.0 600 2x300 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil
MR12
0460 7 460 2x300 4x2/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0520 7 520 2x350 4x3/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0590 7 590 2x400 4x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0650 7 650 2x400 4x4/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0750 7 750 2x450 4x300 1 AWG-350 kcmil 1 AWG-350 kcmil 0820 7 820 2x500 4x350 1 AWG-350 kcmil 1 AWG-350 kcmil

Vacon 100 Series Specifications

General

Product type	AC Drive
Output frequency range	0 - 320 Hz
Enclosure rating	IP20
Fieldbus	Modbus RTU
Output voltage range	0 - Supply voltage
Control method	Scalar control (V/f), Sensorless vector control
Protection features	Overcurrent, Overvoltage, Undervoltage
Communication options	Modbus RTU
Ambient temperature range	-10°C to +40°C
Supply voltage	3-phase 208-240 V, 3-phase 380-480 V
