Vacon 100 Series User Manual

10
THE CABLE AND FUSE SIZES FOR VACON
®
100 FAMILY
IN NORTH AMERICA, MAINS VOLTAGE 525600 V
Enclosure
size
Type IL [A]
Fuse
(class T)
[A]
Mains, motor and
brake resistor*
cable (Cu) [AWG]
Terminal cable size
Mains cable
terminal
[AWG/kcmil]
Ground terminal
[AWG/kcmil]
MR5
(600V)
0004 6 3.9 6 14 20-6 17-8 0006 6 6.1 10 14 20-6 17-8 0009 6 9.0 10 14 20-6 17-8 0011 6 11.0 15 14 20-6 17-8
MR6
0007 7 7.5 10 12 13-0 13-2 0010 7 10.0 15 12 13-0 13-2 0013 7 13.5 20 12 13-0 13-2 0018 6 / 0018 7 18.0 20 10 13-0 13-2 0022 6 / 0022 7 22.0 25 10 13-0 13-2 0027 7 / 0027 7 27.0 30 8 13-0 13-2 0034 6 / 0034 7 34.0 40 8 13-0 13-2
MR7
0041 6 / 0041 7 41.0 50 6 9-2/0 9-2/0 0052 6 / 0052 7 52.0 60 6 9-2/0 9-2/0 0062 6 / 0062 7 62.0 70 4 9-2/0 9-2/0
MR8
0080 6 / 0080 7 80.0 90 1/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0100 6 / 0100 7 100.0 110 1/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0125 6 / 0125 7 125.0 150 2/0 1 AWG-350 kcmil 1 AWG-350 kcmil

Vacon 100 Series Specifications

General

Product type	AC Drive
Output frequency range	0 - 320 Hz
Enclosure rating	IP20
Fieldbus	Modbus RTU
Output voltage range	0 - Supply voltage
Control method	Scalar control (V/f), Sensorless vector control
Protection features	Overcurrent, Overvoltage, Undervoltage
Communication options	Modbus RTU
Ambient temperature range	-10°C to +40°C
Supply voltage	3-phase 208-240 V, 3-phase 380-480 V
