Vacon 100 Series User Manual

6
THE TECHNICAL DATA OF THE VACON
®
100 FAMILY AC DRIVES
Technical item or function Technical data
Mains connection
Input voltage U
in
208-240V, 380-500V, 525-600V,
525-690V,-10%…+10% *
Input frequency 50-60 Hz, -5...+10%
Connection to mains Once per minute or less
Starting delay 6 s (MR4 to MR6), 8 s (MR7 to MR12)
Mains
• Mains types: TN, TT, and IT
• Short circuit current:
the maximum short circuit current
must be < 100 kA.
Motor connection
Output voltage 0-U
in
Continuous output
current
I
L
: Ambient temperature max. +40 °C
overload 1.1 x I
L
(1 min/10 min)
I
H
: Ambient temperature max. +50 °C
overload 1.5 x I
H
(1 min/10 min)
I
H
in 600/690 V drives and MR10-MR12:
Ambient temperature max. +40 °C
overload 1.5 x I
H
(1 min/10 min)
Output frequency 0-320 Hz (standard)
Frequency resolution 0.01 Hz

Vacon 100 Series Specifications

General

Product type	AC Drive
Output frequency range	0 - 320 Hz
Enclosure rating	IP20
Fieldbus	Modbus RTU
Output voltage range	0 - Supply voltage
Control method	Scalar control (V/f), Sensorless vector control
Protection features	Overcurrent, Overvoltage, Undervoltage
Communication options	Modbus RTU
Ambient temperature range	-10°C to +40°C
Supply voltage	3-phase 208-240 V, 3-phase 380-480 V
