Vacon 100 Series User Manual

8
THE CABLE AND FUSE SIZES FOR VACON
®
100 FAMILY
IN NORTH AMERICA, MAINS VOLTAGE 208240 V AND 380500 V
Enclosure
size
Type IL [A]
Fuse
(class
T/J) [A]
Mains, motor
and brake
resistor* cable
(Cu) [AWG]
Terminal cable size
Mains cable
terminal
[AWG/kcmil]
Ground terminal
[AWG/kcmil]
MR4
0003 2 / 0003 5 3.7 / 3.4 6 14 24-10 17-10 0004 2 / 0004 5 4.8 6 14 24-10 17-10 0006 2 / 0005 5 6.6 / 5.6 10 14 24-10 17-10 0008 2 / 0008 5 8.0 10 14 24-10 17-10 0011 2 / 0009 5 11.0 / 9.6 15 14 24-10 17-10 0012 2 / 0012 5 12.5 / 12.0 20 14 24-10 17-10
MR5
0018 2 / 0016 5 18.0 / 16.0 25 10 20-6 17-8 0024 2 / 0023 5 24.0 / 23.0 30 10 20-6 17-8 0031 2 / 0031 5 31.0 40 8 20-6 17-8
MR6
0038 5 38.0 50 4 13-0 13-2 0048 2 / 0046 5 48.0 / 46.0 60 4 13-0 13-2 0062 2 / 0061 5 ** 62.0 / 61.0 80 4 13-0 13-2
MR7
0075 2 / 0072 5 75.0 / 72.0 100 2 9-2/0 9-2/0 0088 2 / 0087 5 88.0 / 87.0 110 1 9-2/0 9-2/0 0105 2 / 0105 5 105.0 150 1/0 9-2/0 9-2/0
MR8
0140 2 / 0140 5 140.0 200 3/0 1 AWG-350 kcmil 1 AWG-350 kcmil 0170 2 / 0170 5 170.0 225 250 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil 0205 2 / 0205 5 205.0 250 350 kcmil 1 AWG-350 kcmil 1 AWG-350 kcmil

Vacon 100 Series Specifications

General

Product type	AC Drive
Output frequency range	0 - 320 Hz
Enclosure rating	IP20
Fieldbus	Modbus RTU
Output voltage range	0 - Supply voltage
Control method	Scalar control (V/f), Sensorless vector control
Protection features	Overcurrent, Overvoltage, Undervoltage
Communication options	Modbus RTU
Ambient temperature range	-10°C to +40°C
Supply voltage	3-phase 208-240 V, 3-phase 380-480 V
