Vacon 100 Series User Manual

13
THE TIGHTENING TORQUES OF CABLE TERMINALS
* = The tightening torque for a torx screw. ** = The tightening torque for an Allen screw.
Enclosure
size
Type
Tightening torque:
the mains cable and
motor cable terminals
Tightening torque:
the grounding
clamps for cable
shield
Tightening torque:
the grounding clamps for
grounding conductor
Nm lb-in. Nm lb-in. Nm lb-in.
MR9
0261 2 - 0310 2 0261 5 - 0310 5 0144 6 - 0208 6 0144 7 - 0208 7
40 354 1.5 13.3 20 177
MR10
0385 5 - 0590 5 0261 6 - 0416 6 0261 7 - 0461 7
55-70 * 490-620 * 1.5 13.3 20 177
MR12
0650 5 - 1180 5 0460 6 - 0820 6 0460 7 - 0820 7
55-70 * 490-620 * 1.5 13.3 20 177

Vacon 100 Series Specifications

General

Product type	AC Drive
Output frequency range	0 - 320 Hz
Enclosure rating	IP20
Fieldbus	Modbus RTU
Output voltage range	0 - Supply voltage
Control method	Scalar control (V/f), Sensorless vector control
Protection features	Overcurrent, Overvoltage, Undervoltage
Communication options	Modbus RTU
Ambient temperature range	-10°C to +40°C
Supply voltage	3-phase 208-240 V, 3-phase 380-480 V
