2
vacon • 7 Modbus - general info
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
Figure 2.Principal example diagram of Modbus
If you need to contact Vacon service in problems related to Modbus, please send a description of the
problem together with the Drive Info File to fieldbus@vacon.com.
Ethernet
Modbus
RTU
master
Switch
Modbus TCP
Modbus RTU
