AV Bridge MATRIX PRO
Part Numbers:
999-8230-000 North America
999-8230-001 International
Compatible Cameras:
Vaddio HD-Series
Vaddio RoboSHOT-Series
Vaddio WideSHOT
Vaddio ZoomSHOT
Vaddio CeilingVIEW Doc Cam
Video Formats Supported:
NTSC and PAL
Video Switcher:
4 x 2
Video Transitions:
Cross Fade, Cut
Video Inputs (1-3):
Three (3) RJ-45: Vaddio HSDS from cameras
Three (3) Alternate HDMI
Video Input 4:
One (1) HDMI Computer or alternate source input
One (1) RGBHV Input on DE-15 Connector
Video Input Resolutions:
HDMI IN (sRGB): 1080p 60/59.94/50 Hz, 1080i 59.94/50 Hz, 720p 60/59.94/50 Hz
YPbPr Camera IN:
1080p/60/59.94/50/30/25 frames/sec, 1080i/59.94/50 fields/sec, 720p/60/59.94/50
frames/sec
RGBHV IN: (VESA RESOLUTIONS):
1280 x 720@60Hz (16:9), 1280x768@60Hz (15:9)m, 1280x800@60Hz (16:10), 1360 x
768@60Hz (16:9), 1024 x 768@60Hz (4:3 centered in 16:9 frame)
EDID Supported Resolutions:
1080p/60/59.94/50/frames/sec, 720p/60/59.94/50Hz frames/sec, 1440 x 900@60Hz,
1360x768 @ 60Hz, 1280x800 @ 60 Hz
Program Output:
One (1) HDMI Program Output
One (1) Vaddio HSDS Display Output
Video Output Resolutions:
HDMI and Vaddio Display HSDS:: 1080p 60/59.94/50/30/25 Hz, 1080i 59.94/50 Hz,
720p 59.94/50/30/25 Hz
USB:
USB: Type B USB 2.0 compliant connector
Supported Drivers: USB Video Class, (UVC), USB Audio Class (UAC)
No Custom Drivers, Custom Programs or Custom Headaches
USB Streaming Resolutions:
MJPEG and PCM Audio Up to 720p 30 Frames (limits of USB 2.0)
Network:
Shielded RJ-45 10/100 Base-T
Network Streaming Resolutions:
H.264 & AAC Audio up to 1080p 30/25 Frames
Audio I/O
Four (4) EasyMic Ports, Four Mic/Line Inputs (with 4-AECs and phantom power for
mics), Four (4) Line Outputs (8x4 Matrix Mixer)
Video/Audio DSP:
Video: Auto Scaling, Noise Filtering and De-interlacing
Audio: Compressor, Equalization, Filters, AEC
Camera Control Ports:
Six (6) RS-232 on RJ-45F
Control Interface:
One (1) RS-232 on DE-9
Control:
Embedded Web Server: for configuration and Administration
Front Panel Controls: for viewing configurations and AV Muting
Telnet: on network RJ-45 Port
RS-232 Port: (Feature to be added at second firmware release)
LCD Display:
8-line backlit LCD display
Power Requirements:
24 VDC, 3.75 Amp Switching Power Supply
Trigger Inputs:
Configurable Trigger Inputs, contact closure type
Dimensions (H x W x D):
18.93” (480.8mm) W (with rack ears) x 3.47” (88.14mm) H x 8.0” (203.2mm) D
Mass:
5.55643 lbs. (2.5203543 kg)
