AV Bridge MATRIX PRO
AV Bridge Matrix Pro Manual - Document Number 342-0915 Rev C Page 59 of 68
Video stream pip
Specifies PIP behavior.
Synopsis
video stream pip {on | off | toggle | inset [input1 | input2 | input3 | input4]}
Options
on
Turns on the PIP.
off
Turns off the PIP.
toggle
Changes the state of the PIP – on if it was off, or off if it was
on.
inset [input1 | input2
| input3 | input4]
Specifies the source of the PIP.
Examples
video stream pip on
Enables the PIP.
video stream pip toggle
Changes the state of the PIP.
video stream pip inset input2
Sets the source of the PIP to be video input 2.
Video mute
Sets the video mute state or returns its current state.
Synopsis
video mute {get | on | off | toggle}
Options
get
Returns the current state of video muting (on or off).
on
Sets video muting.
off
Restores video.
toggle
Changes the current state of video muting – off if it
was on, on if it was off.
Examples
video mute on
Replace the video with the video mute display.
video mute get
Get the current state of video muting.
Streaming
Can be used to return a list of current settings. At this time, streaming is not configured via the API.
Synopsis
streaming settings get
Example
streaming settings get
Returns current streaming settings in the form
IP Enabled
true
IP Port
554
IP Protocol
RTSP
IP Quality
High Quality (Best)
IP Resolution
720p
IP URL
lobby-conference
USB Enabled
true
