6 Start-up
34 Installation instructions electronicVED 0020288452_00
5. Press the safety switch (1).
6.2 Fitting the product casing
If the cable for the temperature selector
is not plugged into the electronics, the
electronics cannot regulate the power. The
outlet temperature is 30 °C.
▶ Refit the product casing as shown.
Note
Check whether the product cas-
ing has been installed correctly.
6.3 Attaching the product casing
so that it is rotated by 180°
▶ Remove the control panel from the
product casing.
▶ Turn the product casing by 180°.
▶ Install the control panel in the product
casing.
▶ Attach the product casing. (→ Page 34)
