Vaillant MAG AT 11-0/1 GX H User Manual

Product description 3
0020189893_03 atmoMAG Installation and maintenance instructions 7
Applicability: MAG 11-0/1 XI
2
3
5
8
9
10
12
67
4
1
11
1 Atmospheric sensing
device
2 Flue gas sensor
3 Safety overheat cut-off
device
4 Heat exchanger
5 Burner
6 Temperature selector
7 Gas valve
8 Power switch
9 Main switch
10 Electronics box with
battery compartment
11 Ignition electrode
12 Monitoring electrode
Applicability: MAG 14-0/1 GX
2
4
8
9
10
11
12
67
3
1
5
1 Atmospheric sensing
device
2 Flue gas sensor
3 Heat exchanger
4 Burner
5 Generator
6 Temperature selector
7 Gas valve
8 Power switch
9 Main switch
10 Switch box
11 Ignition electrode
12 Monitoring electrode

Vaillant MAG AT 11-0/1 GX H Specifications

General

Brand	Vaillant
Model	MAG AT 11-0/1 GX H
Category	Boiler
Language	English
