Vaisala GMW95 - Transmitter Body; Mounting Base

4
Transmitter Body
HTM10 module
(temperature measurement)
DIP switches for protocol
and serial line settings
HUMICAP
180R sensor
(humidity measurement)
DIP switches for
transmitter address
RS-485 termination jumper
(connects a 120 Ω resistor)
GM10 module
(CO
2
measurement)
Mounting Base
Terminal label
Orientation arrow
Opening for cable
Place for zip tie
Opening for cable
Label for RS-485 baud rate
DIP switch settings
Screw terminals
