Vaisala WXT531 User Manual

Chapter 7 ___________________________________________________ Retrieving Data Messages
VAISALA______________________________________________________________________ 119
Example of the XDR Query (all parameters of each sensor enabled
and NMEA wind formatter set to T):
$--WIQ,XDR*2D<cr><lf>
Example of the response when all the parameters of each sensor are
enabled (NMEA wind formatter set to T):
Wind sensor data
$WIXDR,A,302,D,0,A,320,D,1,A,330,D,2,S,0.1,M,0,S,0.2,M,1,S,0.2,
M,2*57<cr><lf>
Table 19 Transducer IDs of Measurement Parameters
Measurement Transducer ID Type
Wind direction min 0 A
Wind direction average 1 A
Wind direction max 2 A
Wind speed min 0 S
Wind speed average 1 S
Wind speed max 2 S
Pressure 0 P
Air temperature 0 C
Internal temperature 1 C
Relative humidity 0 H
Rain accumulation 0 V
Rain duration 0 Z
Rain current intensity 0 R
Hail accumulation 1
Hail duration 1
Hail current intensity 1
Rain peak intensity 2
Hail peak intensity 3
Heating temperature 2
Supply voltage 0 U
Heating voltage 1 U
3.5 V reference voltage 2
Information field 4
Aux. rain (tipping bucket) 1 V
Solar radiation 3
Snow level 4
Aux. temperature (pt1000) 3 C
