Valcom V-D11025B User Manual

11 12
14
13
16
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
USA
P. 540-563-2000
F. 540-362-9800
www.valcom.com
Flag Mount Installation
13) Thread at least fifteen inches (38.1cm) of
wiring from the gang box through the bottom of
the pole until each wire exits through the hole in
the adapter.
12) Insert the four #8-32x7/16 screws through the
internal-tooth washers, then through the adapter,
and finally into the pole. Use a screwdriver to
tighten the screws so that the adapter does
not move.
11) Detach the frame from the front of the clock
housing by pulling the bottom and top edges away
from the housing.
14) Detach the filter from the clock display board by
pressing inward on the red tabs.
Adapter holeWire Clamp

Valcom V-D11025B Specifications

General

Brand	Valcom
Model	V-D11025B
Category	Clock
Language	English
