5. PACK CONTENTS
The items required for this appliance are packed in sections.
Pack 1 - Fire unit contains:
1 Heat engine.
1 Hood (Dream model only).
1 Louvre assembly (Petrus model only).
1 Loose parts pack including: -
1 Grommet for rear of convection box.
2 Strips of floor sealing tape.
6 Fibre / wooden plugs.
4 Wood screws.
2 Fire retaining cables.
2 Cable adjusters.
4 Eyebolts.
1 Length of self-adhesive foam seal.
1 Inlet “T” connector including pressure test point, nut and olive for 8mm inlet pipe.
1 Alkaline 9V PP3 battery.
1 Ceramic fuel effect pack (Not shown).
3 No.8 x 3/8 screws (Black) for securing the outlet baffle.
4 No.8 x 3/8 screws (Black) for securing the Dream hood.
4 M4 x 25 screws for securing the fascia.
2 Washers for securing the fascia.
1 Smoke match tube.
1 Outlet baffle
1 Control knob
2 M4 x 7mm screws for securing the control knob.
Pack 2 - Petrus Fire front contains
Pack 2 - Dream Fire front contains
1 Fascia 1 Fascia
1 Firefront casting 1 Firefront casting
1 Front cover casting. 1 Front cover casting.
1 Rear screen assembly. 1 Rear upper screen.
2 Screws 2 Screws
Remove all the items carefully to prevent damage. Take special care when handling
the ceramic components. Some items may be contained in the packaging fitments -
Examine the packaging carefully before discarding. Check that all the items are
present and undamaged.
Page 20
© Baxi Heating U.K. Limited 2010.
