7. PACK CONTENTS
The items required for this appliance are packed in sections.
The ceramic walls are fragile. They are packed inside the top fitment as you open
the carton.
Section 1 - Fire unit contains:
1 Burner and convection box unit.
2 Lengths of self adhesive foam seal.
2 Cable clamps.
2 Fire retaining cables.
4 Eyebolts.
7 Wood screws.
7 Fibre / wooden plugs.
2 Strips of floor sealing tape.
1 ‘T’ connector and pressure test point.
1 Nut and olive for 8mm inlet pipe.
1 ‘PP3’ Battery.
4 ‘AA’ Batteries.
1 Smoke match tube.
1 Ceramic wall set.
1 Remote control handset.
1 Port cover.
3 No.8 x 3/8” Tapping Screws (For port cover).
1 Ceramic support.
3 No.8 x 3/8” Tapping Screws (For ceramic support).
1 Rubber grommet (For rear of convector box).
1 Literature pack.
1 Ceramic fuel effect set (Not shown).
1 Tray for ceramic gravel.
2 Window side trims.
2 Fireback spacing brackets.
4 No.8 x 3/8” Tapping Screws (For fireback spacing brackets).
2 Thumbscrews for fascia securing.
2 Washers for fascia securing.
1 Flue Restrictor
3 No.8 x 3/8” Tapping screws
Section 2 - fascia pack contains:
1 Fascia. (Ref. p20)
Carefully remove all the contents. Take special care in handling the ceramic pieces.
Check that all the listed parts are present and in good condition.
