5.10 Installation options.
In the United Kingdom, as supplied, the appliance can be installed in the following
situations:
5.10.1 Conventional fireplace and hearth.-
To a fireplace opening and hearth as shown in figure 4 and complying with BS1251
after removal of the fireback and sufficient material behind the fireback for a debris
catchment space. The required fireplace, hearth, debris catchment area and
clearance dimensions are shown in figure 5.
© GDC Group Ltd. 2013
Page 15
INSTALLER GUIDE
Figure 4. Hearth and
fireplace opening dimensions
Figure 5. Fireplace area.
