2. The ‘main valve knob’ is the knob on the right hand side (See figure 4). Turn this
knob to the ‘OFF’, fully clockwise position .
3. The ‘manual knob’ is the knob on the left hand side (See figure 5). Turn this knob
to the ‘OFF’, fully clockwise position.
4. Place the ‘ON/OFF’ switch to the ‘O’ (Off position).
5. Wait five (5) minutes to clear out any gas. Then smell for gas, including near the
floor. If you smell gas STOP! and follow the safety information below.
- DON’T SMOKE.
- EXTINGUISH ALL NAKED FLAMES.
- DON’T TURN ELECTRICAL SWITCHES ON OR OFF.
- TURN OFF THE GAS SUPPLY AT THE METER OR
TANK AS APPROPRIATE.
- OPEN DOORS AND WINDOWS TO GET RID OF THE
GAS.
- IMMEDIATELY CALL THE GAS EMERGENCY
SERVICE FROM A NEIGHBOURS PHONE - SEE
YOUR LOCAL TELEPHONE DIRECTORY.
If you do not smell gas, proceed as below:
6. Place the ‘ON/OFF switch to the ‘-’ (On position).
7. With the ‘manual’ knob in ‘MAN’
position a manual pilot valve
operator is accessible (See figure
5).
- Fully push down the manual
pilot valve operator using
the end of a pencil or
similar and hold in to start
pilot gas flow. Immediately
light the pilot with a long
match held at 45° at the left
hand side of the pilot (See
figure 6), while continuing
to hold in the manual pilot
valve operator for about ten (10) seconds after the pilot is lit. Release manual
pilot valve operator. If pilot does not stay lit, repeat steps 2 through 7.
NOTE If the pilot does not stay lit after several tries, turn the gas control knob (main
valve knob) to ‘OFF’ and proceed to step 10.
© GDC Group Ltd. 2013
Page 48
OWNER GUIDE
Figure 5. Pilot valve operator
Figure 6. Match location
