Valtir.com 15 Revision D November 2022
Recommended Tools
Documentation
• Manufacturer’s Assembly Manual
• Manufacturer’s Drawing Package
Personal Protective Equipment
• Eye Protection
• Gloves
• Safety Toe Shoes
• Protective Clothing
Cutting Equipment
• Rotary Hammer Drill
• Rebar Cutting Bit
• Concrete Drill Bits – 22 mm [7/8”] (Double-Fluted)
• Grinder, Hacksaw or Torch (optional)
• Drill Bits 1/16” through 7/8”
Important: Valtir recommends using double-fluted drill bits to achieve optimum
tensile strength when applying an approved adhesive to the anchoring system
(p.12).
Hammers
• Sledgehammer
• Standard hammer
Wrenches
• Heavy Duty 1/2” drive impact wrench
• 1/2" drive Sockets: 9/16", 11/16", 3/4", 15/16", 1 1/8", 1 1/4"
• 1/2" drive Deep Well Sockets: 15/16", 1 1/4”
• 1/2" drive Ratchet and Attachments
• 1/2" drive Breaker Bar – 24” long
• 1/2" drive Torque Wrench: 200 ft-lb
• Crescent Wrench: 300 mm [12”]
• Allen Wrench: 3/8”
Important: Because every impact is different, Valtir makes no
recommendation whether use or reuse of any part of the system is
appropriate or acceptable following an impact. It is the sole responsibility
of the project engineer and/or the local highway authority and its engineers
to make that determination. It is critical that you inspect this product after
assembly is complete to make certain that the instructions provided in this
manual have been strictly followed.
