Valtir.com 57 Revision D November 2022
QuadGuard
®
Final Inspection Checklist
Site Location: ___________________________
Date: __________________________________
Inspector: ______________________________
Refer to the QuadGuard
®
manual and/or drawing package.
Clearance of 30” minimum behind rear Fender Panels for movement (p. 19)
Proper Transition Panel is used for the type of barrier (p. 22, 42)
Every borehole and slot in Backup and Monorail is utilized (p. 23, 24, 44, 45,
46, 47)
Anchor stud(s) height is 1.5” or less above the pad (p. 24)
If no transition is used, narrow side panels are used with backup (p. 26,47)
Monorail guides are attached to the Diaphragms with shims (p. 27, 47)
Mushroom Washer tabs lay flat within fender panel slots (p. 29, 51)
Fender Panel nuts are bottomed out on Mushroom Washer bolt (p. 29,52)
Monorail End Cap Assembly in place (p. 31, 53)
Cartridges are level and the same height in each Bay (p. 35, 56)
Nose Cartridge is level (p. 34)
Fender Panel gap is 0.78” or less for Narrow systems (p. 37)
Fender Panel gap is 1” or less for Wide systems (p. 55)
Cartridge types are in properly placed in each Bay (p. 38, 56)
Bolts and nuts are properly tightened throughout the system (p. 37, 56)
Anchor nuts are torqued to adhesive manufacture specification (p. 12)
System is clear of debris
Important: It is critical that you inspect this product after assembly is
complete to make certain that the instructions provided in this manual have
been strictly followed.
