Valtra T194 User Manual

The indicator light on the proline instrument panel blinks, indicating that the
PTO speed control knob is engaged.
3.17.2.5 Deactivating rear power take-off
WARNING: When you do not need the PTO, keep the PTO switch in
the N position.
WARNING: Use the PTO speed control knob for the actual
disengagement and engagement of the PTO. For example, when
leaving the cab, turn the knob to the N position, except when using the
PTO on/off push button on the mudguard (optional).
• Press down the rear PTO switch and push it forward.
AUTO
1
GUID-1F3C8457-93B5-4937-B524-A362B42389C4
1. Switch for rear PTO
3. Operation
- 211 -

Valtra T194 Specifications

General

Max Speed	50 km/h
Wheelbase	2995 mm
Cylinders	4
Engine Type	AGCO Power
Hydraulic System	Load-sensing
